DELL S-Series S5232F-ON Managed L2/L3 1U Black
xOut of Stock
Contact your account manager
- 1U
- 32 x 100GbE QSFP28
- IO - PSU
- 2 x PSU
- OS10
SKU #: 210-APHK
EAN #: 5397184478509
UNSPSC #: 43222612
| Management features | |
|---|---|
| Multicast support | Yes |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| MIB support | IP, IF, LLDP EXT1/3, LAG, Dell-Vendor, TCP, UDP, SNMPv2, ETHERLIKE, SFLOW, PFC |
| Switch layer | L2/L3 |
| Configuring Location Settings (CLI) | Yes |
| Ports & interfaces | |
| Switching optical modules type | 100 Gigabit Ethernet |
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | No |
| Fiber ports quantity | 32 |
| Fiber optic connector | QSFP28 |
| Console port | RJ-45 |
| Network | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Access Control List (ACL) IPv6 entries | 64000 |
| Access Control List (ACL) IPv4 entries | 128000 |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3x |
| VLAN support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| 10G support | Yes |
| Virtual LAN features | Tagged VLAN |
| Virtual LAN features | |
| VLAN support | Yes |
| Virtual LAN features | Tagged VLAN |
| IPv4 & IPv6 features | |
| Access Control List (ACL) IPv6 entries | 64000 |
| Access Control List (ACL) IPv4 entries | 128000 |
| Optical fiber | |
| Fiber optic connector | QSFP28 |
| Switching optical modules type | 100 Gigabit Ethernet |
| Performance | |
| Packet buffer memory | 32 MB |
| Stackable | Yes |
| Internal memory | 16000 MB |
| Built-in processor | Yes |
| Technical details | |
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| Rack mounting | Yes |
| Built-in processor | Yes |
| Compliance certificates | RoHS |
| Data transmission | |
| Packet buffer memory | 32 MB |
| MAC address table | 160000 entries |
| Switching capacity | 3200 Gbit/s |
| Security | |
| Access Control List (ACL) IPv6 entries | 64000 |
| Access Control List (ACL) IPv4 entries | 128000 |
| Multicast features | |
|---|---|
| Multicast support | Yes |
| Protocols | |
| Management protocols | CLI, SNMP, REST, API’s |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Memory | |
| Packet buffer memory | 32 MB |
| Internal memory | 16000 MB |
| Design | |
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| LED indicators | Yes |
| Rack mounting | Yes |
| Ventilation system | Front-to-back airflow |
| Number of fans | 4 fan(s) |
| Indication | |
| LED indicators | Yes |
| Mobile network | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Power | |
| Power consumption (max) | 635 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 360 W |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 2167 BTU/h |
| Weight & dimensions | |
| Width | 434 mm |
| Depth | 460 mm |
| Height | 44 mm |
| Weight | 9.8 kg |
Innovative data center architectural agility with 25/40/50/100GbE switches
Gain the flexibility to transform your data centers with high-capacity network fabrics that are easy to deploy, cost-effective and provide a clear path to a software-defined data center. They offer:
- High density for 25/40/50/100GbE deployments in top-of-rack, middle-of-row, and end-of-row deployments
- A choice of S5048F-ON, S5148F-ON, S5224F-ON, S5248F-ON, S5296F-ON and S5232F-ON 25 &100GbE, S6000-ON and S6010-ON 40GbE switches and the S6100-ON 10/25/40/50/100GbE modular switch
- S6100-ON modules that include: 16-port 40GbE QSFP+; 8-port 100GbE QSFP28; combo module with four 100GbE CXP ports and four 100GbE QSFP28 ports
- An ideal solution for modern workloads and applications designed for the open networking era
Dell: Open Networking Switch Market Leader
IT Brand Pulse 2019 Networking Brand Leaders
Dell: Open Networking Switch Performance Leader
IT Brand Pulse 2019 Networking Brand Leaders
Dell: Open Networking Switch Innovation Leader
IT Brand Pulse 2019 Networking Brand Leaders
2017 CRN Annual Report Card: SMB Networking Winner
"Dell swept the SMB Networking category this year, claiming all three subcategories." — CRN®
Optimized for the open networking era
Get more agility, more choices and lower costs than proprietary networks with select open-standards-based ON (open networking) switches. - Disaggregated-hardware/software solutions bring new levels of freedom and flexibility to your data center.
- Support for Open Network Install Environment (ONIE) enables zero-touch installation of alternate network operating systems.
- Your choice of network operating system helps simplify data-center fabric orchestration and automation.
- A broad ecosystem of open-source and Linux-based applications and tools provides more options to optimize and manage your network.
Ready for software-defined networking
Deploy modern workloads and applications while providing an easy on-ramp to software-defined networking (SDN). - Support for OpenFlow v1.3 provides interoperability with industry-standard OpenFlow controllers.
- VXLAN Layer 2 Gateway enabling allows connection to hypervisor-based overlay networks.
- Third-party OS support provides an easy entry point to SDN for part or all of your production environment.
Dell PowerSwitch S5232F-ON
Build a high-performance, cost-efficient data center leaf/spine fabric with this spine fabric switch featuring 32 x 100GbE QSFP28 ports. The S5232F-ON also supports Open Network Install Environment (ONIE) for zero-touch installation of network operating systems.
Consulting
Dell network consultants provide expert guidance to help you optimize and transform the network environment for the demands of today’s multi-cloud infrastructures. Our deep infrastructure and application expertise combined with sophisticated network analysis toolsets address a wide range of network technology and process challenges.
Deployment
Leverage the Dell ProDeploy Enterprise Suite to get your network installed and configured. Our experts can free your IT staff to focus on your core business, minimize downtime and give you the confidence that the job will be done right, the first time.
Support
Gain access to ProSupport technical experts who can assist with your most complex networking challenges. The Dell ProSupport Enterprise Suite provides networking support around the clock and around the globe, helping your team maintain a high level of productivity.
Education
Dell offers flexible training programs so your staff can build the right skills to successfully manage and utilize your network to its full potential. Through our personalized approach, your staff gets the exact training they need to improve productivity and adoption, decrease downtime, and reduce end-user support calls.
Flexible architectural agility
Designed for architectural agility and flexibility to help data centers smoothly migrate to a software-designed data center.
Designed for architectural agility and flexibility to help data centers smoothly migrate to a software-designed data center.
